Film width: Max.420mm
Film width range(bag former): 140-420mm
Bag width: 65-200mm
Bag length: 80-300mm
Film roll diameter: Max.320mm
Packing rate: 10-50bag/min
Measurment range: 150-1100ml
Film thickness: 0.07-0.15mm
Power: 220V,50HZ, single phase
Machine size: (L)3876*(W)2231*(H)3457mm
Machine weight: 500kg
New design, beautiful appearance, reasonable structure, more advanced technology;
Imported PLC computer control system, color touch screen easy, intuitive and efficient;
Import servo film transporting system, import color sensor, accurate positioning machine performance packaging beautifully;
Multiple automatic alarm proton educing the maximum loss;
Bag-shaped variety, can provide customers with pillow-shaped bags, thrust Angle bags, hang hole bags,even bags;
Suitable for packing all kinds of rice, nuts, dry fruits, puffed food, candy, peanut, melon seeds, seeds, popcorn, salt, sugar, chips and other powdered, granular, strip product etc packing.
Free consultation service before, during and after sales;
Free project planning and design services;
Free debugging of equipment until everything is functional;
Free training of equipment maintenance and operation personally;
Free new production techniques and formulas;
Machine provide 1 year complete warrantee and full lifetime maintenance service.
| Model： | HF-420 |
| Film width | Max.420mm |
| Film width Range(bag former) | 140-420mm |
| Bag Width: | 65-200mm |
| Bag Length: | 80-300mm 320mm |
| Film roll Diameter: | Max.320mm |
| Packing rate: | 5-50bag/min |
| Measurment range: | 150-1100ml |
| Film thickness: | 0.07-0.15mm |
| Power: | 220V,50HZ,Single Phase |
| Machine size: | (L)4050*(W)2600*(H)3600 |
| Machine Weight: | 1120kg |
| Remark | Pneumatic Type |
