Packing speed：25~70 bags/min
Film size：900mm
Package length：150-600mm
Package width：350mm
General power：7.5Kw
It is suitable for the packaging of large size products such as chocolate, flatbread, multi-packet combination of sachima, multi-packet combination of baked cake and so on.
The machine is controlled by seven servos.
The knife seal is reciprocating structure, and the sealing is smooth and beautiful
The machine packaging range is large, suitable for packaging all kinds of large specifications, large size products.
Ten inch touch screen display, easy operation, clear working state.
Can store a variety of product parameters and formulations, do not need to repeat Settings, download and use.
Automatic adjustment of bag length, no manual setting.
The machine has higher precision and the sealing and cutting position is accurate.
Stop position, coding position can be arbitrarily set in the touch screen, just click, convenient and fast.
Simple mechanical structure, convenient and intuitive debugging, low after-sales maintenance cost.
|
Model |
MC-801W |
|
Distance between centers |
160mm |
|
Packing speed |
20-70 bag/min |
|
Film size |
900 mm |
|
Package length |
120-600mm |
|
Package width |
350mm |
|
Package height |
140mm |
|
General power |
7.5Kw |
|
Packaging film type |
PP、CPP、PVC、PS、EVA、PET、PVDC/PVC、OPP/CPP ETC. |
|
Power supply |
220v/50Hz |
|
Machine size |
5215 x 1560 x1537 mm |
|
Net weight |
1500 kg |
